Technical Specifications Enclosure
Plastic, type PC (UL 94 V-0). Dimensions: 93mm x 53mm x 58mm. Weight: 85 g Color
Light Grey. RAL 7035. Terminal wiring (for power supply and low-voltage signals)
Per terminal: solid wires or stranded wires (twisted or with ferrule)
1 core: 0.5 … 2.5mm2
2 cores: 0.5 … 1.5mm2
3 cores: not permitted Console Port
Mini USB port for console usage Mounting
Wall.
DIN rail EN60715 TH35. BACnet MS/TP port
1 x EIA485 Plug-in screw terminal block (2 poles + GND) BACnet IP port
1 x Ethernet 10/100BT RJ45. LED indicators
6 x Gateway/Communication status Operational temperature
0°C to +70°C Operational humidity
5% to 95%, non-condensing Isolation Voltage
4000 VDC (between AC unit and EIA-485)
1000 VDC (between AC unit and console) Protection
IP20 (IEC60529). RoHS conformity
Compliant with RoHS directive (2002/95/CE). Certifications
CE conformity to EMC directive (2004/108/EC) and Low-voltage directive (2006/95/EC) EN 61000-6-2 ;EN 61000-6-3; EN 60950-1; EN 50491-3
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference
2) This device must accept any interference received, including interference that may cause undesired operation.
