Johnson Controls - M9104-GGA-3S - Damper Actuator 4 Nm Nsr 4 Nm Dpr Act 0 To 10 Vdc 24 Vac 50/60 Hz Terminal Screws

 35 in-lb Damper Actuator 24V 0(2)-10 VDC w/screw terminals

Description:



  • Provides a running torque of 35 lb·in (4 N·m)
  • Nominal travel time 60 seconds at 60 Hz (72 seconds at 50 Hz) for 90° of rotation
  • VA rating: 3.6
  • 0(2) to 10VDC, 0(4) to 20 mA (w500? Resistor)
  • Electrical connection: screw terminals



Control Signal: Proportional 0(2) to 10VDC, 0(4) to 20 mA; Mfg. #: M9104-GGA-3S; Torque: 35 lb-in; Type: Non-Spring

Customer Rating: Not Rated Yet
Quick Order Number: 15
Manufacturer: Johnson Controls
Part Number: M9104-GGA-3S
Weight: 1.19 lbs
Stocked Item*: Yes
Quantity Available*: 7
Price: $99.75
Quantity:

* If an order is placed where the item is a "Non-Stocked Item" or the quantity ordered is more than the quantity available, all items in stock will be shipped and the remainder of the items will be shipped as soon as we get the "backordered" items in.



Product Specifications



Product Specifications

Type Non-Spring
Torque 35 lb-in
Control Signal Proportional 0(2) to 10VDC, 0(4) to 20 mA
Shipping Weight 1.00
Shipping Width 3.00
Shipping Length 3.00
Shipping Height 6.00
